Ballast Water Management System

Introduction

The Ballast Water Management System(BWMS) is a equipment system to remove harmful marine organism and pathogens from the ballast water tank in ships in order to prevent destruction or disturbance of the marine ecosystem.

At the International Maritime Organization (IMO) in 2004, the International Convention for the Control and Management of Ship's Ballast Water and Sedimentes was adopted to make it mandatory to install BWMS.

There are several different methods of the system, which are ultraviolet irradiation, electrolysis and ozone dispensing methods. Our products are rectifiers and electrolytes used in BWMS of Japan's PANASONIC environment engineering.


Advantage

1. High-performance IN-LINE electrolyte specially designed for BWMS : High sterilization treatment

2. No filter system for organisms

  • Thanks to the combination of electrolyte and stirrer with high sterilization function, no pretreatment is required to remove more than 50um of life. Therefore, the processing defect RISK is greatly reduced and the flow/time of the BALLAST is stable.

3. Reduction of operating cost

  • Sterilizing agents can be produced on board with only a small amount of salt.

  • No pre-filteration system can reduce huge amount of cost of consumable material.

Application

Application

For more information, please download the documents below

Introduction in English Introduction in Japanese
MODEL CAP.(m3/h) Power Consumption(㎾)
PEU300

~330

30PSU : 13


1.5PSU : 49
PEU600

~600

30PSU : 28


1.5PSU : 100
PEU1200

~1200

30PSU : 56


1.5PSU : 200
PEU1800

~1800

30PSU : 84


1.5PSU : 300
  • MODEL :

    PEU300

  • CAP.(m3/h):

    ~330

  • 소비전력(kW) :

    30PSU : 13

    1.5PSU : 49

  • MODEL :

    PEU600

  • CAP.(m3/h) :

    ~600

  • 소비전력(kW) :

    30PSU : 28

    1.5PSU : 100

  • MODEL :

    PEU1200

  • CAP.(m3/h) :

    ~1200

  • 소비전력(kW) :

    30PSU : 56

    1.5PSU : 200

  • MODEL :

    PEU1800

  • CAP.(m3/h) :

    ~1800

  • 소비전력(kW) :

    30PSU : 84

    1.5PSU : 300

Manufacturer

PANASONIC ENVIRONMENTAL ENGINEERING_BWMS
  • Origin : Japan
KOOSOO　Heavy Electric Co., Ltd. _ Rectifier
http://www.koosoo.co.kr
  • Origin : Republic of Korea
ELECSYS _ Electrolytic Cell
  • Origin : Republic of Korea
ELECSYS _ Electrolytic Cell
  • Origin : Republic of Korea

Person in charge

Chungsun Kim (Mr.)
  • Mobile Phone :　+82-10-4131-1830
  • E-mail : cskim@mtccorp.co.kr
